Reference: CXM-CASE1BLK
PC Engines ALix 2D3/2D13, APU and OpenVox IPC100/IPC110/IPC120 enclosure with 2 x 2.5" HDD Mounting and 2 optional LAN, 2 WiFi, black.
PC Engines ALix 2D3/2D13, APU and OpenVox IPC100/IPC110/IPC120 enclosure with 2.5" HDD Mounting and 2 optional LAN, 2 WiFi, black.
Tools needed: Phillips screw driver, 5 mm or 3/16" nut driver. Remove hex nuts from DB9 connector of ALIX board. Mount ALIX board in enclosure, then fasten all screws and hex nuts. CF card can be secured with Kapton tape to the CF socket, or a strip of elastic rubber (e.g. sealing strip for windows) on the inside of the top cover.
Data sheet
PC Engines ALix 2D3/2D13, APU and OpenVox IPC100/IPC110/IPC120 enclosure with 2 x 2.5" HDD Mounting and 2 optional LAN, 2 WiFi, black.
Enclosure designed for ALIX.2* boards. Cutouts for 3 LEDs and 1 switch in front, cutouts for DB9, 2 LAN, 3 or 2 SMA connectors, DC jack in back. Enclosure made of anodized or painted aluminum. Dimensions 168 mm wide x 157 mm deep x 30 mm high. RoHS compliant.
