7 inches Touch Display(eDP) for LattePanda Alpha & Delta

Name: 7 inches Touch Display(eDP) for LattePanda Alpha & Delta
Brand: LattePanda
SKU: FIT0551
Price: 79.9 USD
Availability: PreOrder

Ships in 5~10 Days

US$79.90

This display adopts IPS screen technology, support 178-degree visual Angle, 1024 x 600 high resolution and high color saturation, achieve excellent picture.

Ask a Quote

Description

Excellent Visual Effect
This display adopts IPS screen technology, support 178-degree visual Angle, 1024 x 600 high resolution and high color saturation, achieve excellent picture.

Designed For HMI and Portable Projects
FIT0551 powered.png

We have made many product design optimizations for HMI and portable project requirements. For example, HMI scenarios are often complex and dusty, but this display uses a fully fit design to perfectly prevent dust from entering the screen, and also effectively reduces the reflection of light. In order to make the screen easy to be installed, the screen edge comes with the special double-sided adhesive tape, which can be easily and firmly fixed.

Best Compatibility
Unlike other normal HDMI screens, this display uses eDP interface, and has the best compatibility with LattePanda alpha & delta (not compatible with LattePanda V1.0). It allows you to set screen power, brightness, contrast and other parameters directly in the OS or APIs.

FEATURES

1024 x 600 high resolution
Capacitive screen

DOCUMENTS

Product Details

Display Resolution: 1024 x 600
Transmittance: 85%
Surface Hardness: 6H
Connector: 10cm FPC Extension Cable
Response Time: ≤16ms
Tapping Durability: 200,000,000 times
Compatible with: LattePanda Alpha & Delta
Dimension: 180*110*5 mm / 7.1*4.3*0.2 inches
Package Includes: 1 x 7”eDP Touch Display, 1 x 30pin eDP cable
Board Category: LattePanda Display

Reference FIT0551
