Works with the ODROID-C1 on-board IR receiver

Infrared remote controller
12 Keys function
37.9Khz Carrier Frequency
NEC standard protocol

Key maps
- Power
- Mute
- Home
- Up (Up Arrow)
- Down (Dn Arrow)
- Left (Left Arrow)
- Right (Right Arrow)
- OK (Enter)
- Menu
- Back (ESC)
- Vol +
- Vol -





IR Remote Controller (Android)



Button
IR code Scancode Android
Power 0xDC 116 KEYCODE_POWER
Mute 0x88 113 KEYCODE_VOLUME_MUTE
Home 0x82 102 KEYCODE_HOME
OK 0xCE 97 KEYCODE_DPAD_CENTER
Up 0xCA 103 KEYCODE_DPAD_UP
Left 0x99 105 KEYCODE_DPAD_LEFT
Right 0xC1 106 KEYCODE_DPAD_RIGHT
Down 0xD2 108 KEYCODE_DPAD_DOWN
Menu 0xC5 139 KEYCODE_MENU
Back 0x9A 158 KEYCODE_BACK
Volume Down 0x81 109 KEYCODE_VOLUME_DOWN
Volume Up 0x80 104 KEYCODE_VOLUME_UP



IR Remote Controller (Linux)



Button
IR code Scancode XF86Map/Linux
Power 0xDC 124 XF86PowerOff
Mute 0x88 121 XF86AudioMute
Home 0x82 180 XF86HomePage
OK 0xCE 36 Return/Enter
Up 0xCA 111 Up Arrow
Left 0x99 113 Left Arrow
Right 0xC1 114 Right Arrow
Down 0xD2 116 Down Arrow
Menu 0xC5 135 Menu
Back 0x9A 166 XF86Back
Volume Down 0x81 122 XF86AudioLowerVolume
Volume Up 0x80 123 XF86AudioRaiseVolume
ODIRREM

Data sheet

Color
Black
Manufacturer Code
0x4DB2
Input Power
Powered by 2 x AAA batteries (not included)
Board Category
ODROID-C0
ODROID-C1+
ODROID-C2
ODROID-C4
ODROID-GO
ODROID-HC
ODROID-N2+
Return Warranty
No Returns
Manufacturer Warranty
No Returns
