APU3C2 Blue Combo Kit
APU3C2 Blue Combo Kit
APU3C2 Blue Combo Kit
  • On sale!
  • -US$17.699115

APU3C2 Blue Combo Kit

Tax excluded

The APU3C2 Platform is the alternate next generation of low cost APU series (APU2C4) from PCEngines.

Enclosure Type :
Storage :
In Stock, Shipping Now


Secure Transaction


Shipping Directly from Canada


Customer-Friendly Return Policy

This APU3C2 combo kit enables you to use it for more than 40 different applications in the field of embedded devices, like broadband management, security applications, custom linux based OS, routing or many more. This kit can also be deployed for multimedia applications as well as WLAN access points or VPN-Gateways.

This board version is targeted at applications that require two 3G / LTE modems. SIM sockets can be swapped under GPIO control, enabling failover between two different networks even when only one modem is used. Another feature is the build option for a regular PCI express slot on the side.

Combo Kit Includes:

1 x Motherboard (APU3C2)
1 x Blue Enclosure (3 LAN, USB and 2 Antenna Cutouts)
1 x Power Adapter (12v 2A)

Does not Include:

OS: No OS installed
Enclosure Type: Labelled (You can select from Options tab)
Storage: SD Card or mSATA (Select appropriate storage card from options tab)
Console Cable: Null modem cable to connect to the serial console
Ethernet Cable: Cat 5 ethernet cables to connect to your network


Data sheet

Processor (CPU)
AMD Embedded G series GX-412TC, 1 GHz quad Jaguar core with 64 bit and AES-NI support, 32K data + 32K instruction cache per core, Shared 2MB L2 cache
2 GByte DDR3-1333 (not expandable)
DB9 Serial Port, 2 x USB 3.0 external, 4 x USB 2.0 internal, Three Front panel LEDs, Push Button
Board Size
6 x 6" (152.4 x 152.4 mm) - same as APU1D, ALIX2D13
None (Select from Options)
Storage Controller
mSATA, SD Card
Enclosure Color
Enclosure Cutouts
3 x Ethernet, 1 x USB, 2 x SMA, 3 x LED, 1 x Reset button
Ethernet Ports
3 Gigabit Ethernet channels (Intel i211AT)
Package Includes
System Board (APU3C4), Blue Enclsoure, Power Adapter, 3mm alu heat spreader
CoreBoot Open Source System BIOS with support for iPXE and USB boot
3 miniPCI express (J14 USB or mSATA, with SIM; J15 USB only, with SIM; J16: full miniPCI express, but no SIM, intended for wifi). GPIO header, optional I2C bus, COM2 (3.3V RXD / TXD).
Power Adapter
12v 2A with US Plug
12V DC
Board Category
Return Warranty
Standard 30 Days
Manufacturer Warranty
2 Years Limited Warranty
