Availability: 4 In Stock
It is a high-performance mini-ITX embedded board with AMD GX Series (Quad-Core) CPU 1GHz with 64 bit and 2MB L2 cache featuring 4 Intel i211AT & 4GB DDR3-1333 DRAM.
*Heat Spreader Kit for APU Board is included
APU3D4 Black Combo Kit
Reference: A3D4BK
US$225.00
The APU3D4 Platform is the alternate next generation of low cost APU series (APU2E4) from PCEngines. It is a high performance mini-ITX embedded board with AMD GX Series (Quad-Core) CPU 1GHz with 64 bit and 2MB L2 cache featuring 3 Intel i211AT & DDR3-1333 DRAM with optimized for 3G/LTE Modems.
*Heat Spreader Kit for APU Board is included
This APU3D4 combo kit enables you to use it for more than 40 different applications in the field of embedded devices, like broadband management, security applications, custom linux based OS, routing or many more. This kit can also be deployed for multimedia applications as well as WLAN access points or VPN-Gateways.
This board version is targeted at applications that require 2 3G / LTE modems. SIM sockets can be swapped under GPIO control, enabling failover between two different networks even when only one modem is used. Another feature is the build option for a regular PCI express slot on the side.
Combo Kit Includes:
1 x Motherboard (APU3D4)
1 x Black Enclosure (3 LAN, USB and 2 Antenna Cutouts for APU2D4) (Not Labelled)
1 x Power Adapter (12v 2A)
Does not Include:
OS: No OS is installed
Enclosure Type: Labelled (You can select from Options)
Storage: SD Card or mSATA (Select appropriate storage card from options)
Console Cable: Null modem cable to connect to the serial console
Ethernet Cable: Cat 5 ethernet cables to connect to your network
A3C4BK
Data sheet
- Processor (CPU)
- AMD Embedded G series GX-412TC, 1 GHz quad Jaguar core with 64 bit and AES-NI support, 32K data + 32K instruction cache per core, Shared 2MB L2 cache
- DRAM
- 4 GByte DDR3-1333 (not expandable)
- I/O
- DB9 Serial Port, 2 x USB 3.0 external, 4 x USB 2.0 internal, Three Front panel LEDs, Push Button
- Board Size
- 6 x 6" (152.4 x 152.4 mm) - same as APU1D, ALIX2D13
- Storage
- None (Select from Options)
- Storage Controller
- mSATA, SD Card
- Enclosure Color
- Black
- Enclosure Cutouts
- 3 x Ethernet, 1 x USB, 2 x SMA, 3 x LED, 1 x Reset button
- Ethernet Ports
- 3 Gigabit Ethernet channels (Intel i211AT)
- Package Includes
- System Board (APU3C4), Black Enclsoure, Power Adapter, ALU 3mm Heat Spreader, Thermal Pads
- Firmware
- CoreBoot Open Source System BIOS with support for iPXE and USB boot
- Expansion
- 3 miniPCI express (J14 USB or mSATA, with SIM
J15 USB only, with SIM
J16: full miniPCI express, but no SIM, intended for wifi). GPIO header, optional I2C bus, COM2 (3.3V RXD / TXD). - Power Adapter
- DC Output: 12v 2A with US Plug
- Power
- 12V DC
- Board Category
- APU3
- Return Warranty
- Standard 30 Days
The APU3D4 Platform is the alternate next generation of low cost APU series (APU2E4) from PCEngines. It is a high performance mini-ITX embedded board with AMD GX Series (Quad-Core) CPU 1GHz with 64 bit and 2MB L2 cache featuring 3 Intel i211AT & DDR3-1333 DRAM with optimized for 3G/LTE Modems.
*Heat Spreader Kit for APU Board is included
7 other products in the same category:
Availability: Out of stock
This APU2E4 combo kit enables you to use it for more than 40 different applications in the field of embedded devices, like broadband management, security applications (firewalls) like pfsense and routing.
*Heat Spreader Kit for APU Board is included
Replenishment ETA : End of Feb 2022
Availibility: Based on Orders Received.
Availability: Out of stock
This APU2E4 combo kit enables you to use it for more than 40 different applications in the field of embedded devices, like broadband management, Firewalls, Routing, multimedia Apps as well as WLAN access points or VPN-Gateways.
*Heat Spreader Kit for APU Board is included
Availability: 300 In Stock
It is a high performance mini-ITX embedded board with AMD GX Series (Quad-Core) CPU 1GHz with 64 bit and 2MB L2 cache featuring 3 Intel i211AT & DDR3-1333 DRAM with optimized for 3G/LTE Modems.
*Heat Spreader Kit for APU Board is included
Availability: 300 In Stock
This board version is targeted at applications that require two 3G / LTE modems. SIM sockets can be swapped under GPIO control, enabling failover between two different networks even when only one modem is used. Another feature is the build option for a regular PCI express slot on the side.
*Heat Spreader Kit for APU Board is included
Availability: Out of stock
Then NanoPi R4S is high-end min-router with edge-computing and dual Gbps Ethernet Ports. It works with FriendlyWRT, Ubuntu, Armbian and may more linux based systems.
