APU4D4 Combo Kit
APU4D4 Combo Kit

APU4D4 Combo Kit

Expect Delays
US$248.00

It is a high-performance mini-ITX embedded board with AMD GX Series (Quad-Core) CPU 1GHz with 64 bit and 2MB L2 cache featuring 4 Intel i211AT & 4GB  DDR3-1333 DRAM.

*Heat Spreader Kit for APU Board is included

APU4D4 Pre-Installed Systems

Enclosure Type :
Memory+Storage :
Case Color:
  • Blue
  • Black
  • Red

Quantity Unit price You Save
5 US$233.12 US$74.40
20 US$228.16 US$396.80
50 US$223.20 US$1,240.00

Description

PC Engines Announcment:
We will do a life-time buy for a quantity of the AMD SOC and some other key components. We are willing to schedule customer shipments through end of June 2024. Expect limited supply until late 2023. After about 20 years of WRAP, ALIX and APU, it is time for me to move on to different things.

With our BFN4K product, customers can experience the same level of performance, functionality, and reliability as PCEngines hardware.

The APU4D4 Platform is the alternate next generation of low-cost APU series (APU1D) from PC Engines. This combo kit is set of components for anyone to start their project. APU4D4 is a high-performance mini-ITX embedded board with AMD GX Series (Quad-Core) CPU 1GHz with 64 bit and 2MB L2 cache featuring 4 Intel i211AT & DDR3-1333 DRAM. An ideal choice for pfsense, ipfire, OPNsense or any OS is compatible with Linux Kernel 2.6 or higher.

The PC Engines APU System Board is a Single Board Computer (SBC) that can be used for a variety of applications like LAN Router, Firewalls, Load Balancer, VPN-Router, Thin Clients, compact Server, NAS etc.

Compact, power-efficient and can be booted over the network, via USB-Device, SD-Card, mSATA-SSD-Module and SATA-Connection.

Following the cessation of operations by PCEngines, all orders for PCEngines products will be processed and shipped by PCEngines based on the sequence in which they are received. Upon receipt of any order for PCEngines products, CorpShadow will promptly forward the order to PCEngines and await delivery. It is imperative to note that once an order for any PCEngines system board or other products developed by PCEngines has been placed, CorpShadow will not entertain any requests for cancellation or refund under any circumstances.

Directly ship from Canada!

Instructions for Cooling assembly

Product Details

CPU
AMD Embedded G series GX-412TC, 1 GHz quad Jaguar core with 64 bit and AES-NI support, 32K data + 32K instruction cache per core
DRAM
4 GB DDR3-1333 DRAM
Storage Capacity
Boot from SD card (internal sdhci controller), external USB or m-SATA SSD. 1 SATA + power connector. mSATA is shared with miniPCI express
Ethernet Ports
4 Gigabit Ethernet channels (Intel i211AT)
Power
6 to 12W depending on CPU load
Firmware
Coreboot
Expansion
3 miniPCI express (J13 USB or mSATA, apu4*4: with SIM
J14 USB only, with SIM
J15: full miniPCI express, but no SIM, intended for wifi). GPIO header, optional I2C bus, COM2 (3.3V RXD / TXD)
I/O
DB9 serial port, 2 USB 3.0 external + 2 USB 2.0 internal, three front panel LEDs, pushbutton
Package Includes
1 x APU4D4 System Board, 1 x Enclosure, 1 x Power Adatper, 1 x Heat Spreader
Return Warranty
Standard 30 Days
Manufacturer Warranty
1 Year Limited Warranty
