UPS3 for Odroid C1 / C1+ / C2.
Reference: ODUPS3
Uninterrupted Power Supply is an electrical apparatus that provides emergency power to a load when the input power source, typically mains power, fails. The on-battery runtime of most uninterruptible power sources is relatively short but sufficient to start a standby power source or properly shut down the ODROID.
The UPS3 is designed specifically for the ODROID-C1 / C1+ / C2.
Uninterrupted Power Supply is an electrical apparatus that provides emergency power to a load when the input power source, typically mains power, fails. The on-battery runtime of most uninterruptible power sources is relatively short but sufficient to start a standby power source or properly shut down the ODROID.
It is equipped with a rechargeable 3,000mAh Lithium Polymer battery and a charger with a booster IC for 5V output.
When the AC power source fails, the UPS3 keeps supplying the power to the ODROID-C1/C1+/C2 with the battery. There is a digital output pin to notice the battery low-level warning to the ODROIDs to trigger the shutdown process. And the AC power source available, UPS3 will supply the power to the ODROID board again automatically. It will significantly reduce the risk of data loss by sudden power-down.
It will significantly reduce the risk of data loss by sudden power-down.
Full guide, schematics, PCB layout file and detail information is on Hardkernel's WiKi : http://odroid.com/dokuwiki/doku.php?id=en:odroid-ups3
Software update is required.
PACKAGE INCLUDES :
- 5V/2A Power Supply (US Plug)
- 3000mAh battery pack
- UPS Board
- 2 x 11mm PCB spacer (metal)
- 4 x 5mm screw (metal)
Data sheet
- Compatible with
- ODROID-C1 / C1+ / C2
- Integrated
- Protection PCB Over charge and discharge protection
- Connector
- Molex 51021-0200
- Package Includes
- 3000mAh battery pack, DC Plug Cable soldered UPS2 board, 3pin jumper wire (11mm), 4 x 20mm PCB spacers (Plastic), 4 x 11mm PCB spacers (Metal),4 x 10mm PCB spacers (Plastic), 5V/2A Power Supply
- Battery Life
- Carry out 400 cycle charging / discharging @ 20±5℃ (2-4 hours with load 300mA@5V
- Charging Time
- 1hr 30min ~2 hrs
- Idle Current
- 250 ~ 300mA @5V
- Output Current
- 2000mA @ DC 5V
- Battery Type:
- 3,000mAh Lithium Polymer
- Input Power
- DC 4.8V ~ 5.4V / 2A minimum
- Board Category
- ODROID-C1+
ODROID-C2 - Return Warranty
