Reference: DNMA92
DNMA-92 is an 802.11n a/b/g wifi 2x2 mini-PCI module designed specifically for directly dual-band (2.4/5GHz) integration on DSL motherboards, easing carrier manufacturer’s design cycles to accelerate time-to-market that demand robust link quality and maximum price/performance ratio.
Setting new standards in price/performance ratio, range, reliability, and power consumption, DNMA-92 delivers the ultimate wireless triple play experience for video, voice, and data transmission in the home, for the business, and on the road.
Atheros AR9220 single-chip and 2 antennas design supports 2 simultaneous traffic MIMO streams using up to 2 integrated Tx and Rx assuring a higher quality experience to enhance user’s satisfaction.
Data sheet
DNMA-92 is an 802.11n a/b/g wifi 2x2 mini-PCI module designed specifically for directly dual-band (2.4/5GHz) integration on DSL motherboards, easing carrier manufacturer’s design cycles to accelerate time-to-market that demand robust link quality and maximum price/performance ratio.
Qualcomm Atheros QCA9892
• 2.4GHz, 2x2 MIMO OFDM Technology, up to 400Mbps physical data rate
• 5GHz, 2x2 MIMO OFDM Technology, up to 866.7Mbps physical data rate
• Dual Band 2.4/5GHz 2x2 WiFi 5 (802.11ac Wave 1)
Manufacturer Lead Time:: 60weeks
Ships from Canada.
• Qualcomm Atheros QCA9880
• 5GHz, 3x3 MIMO OFDM Technology, up to 1300Mbps physical data rate
• Single Band 5GHz 3x3 WiFi 5 (802.11ac Wave 2)
• MiniPCIe interface with PCIe 1.2
Ships from Canada.
Qualcomm Atheros QCA6174A-5.
• Supports 2x2 multiple-user, multiple-input, multiple-output(MU-MIMO) with two spatial streams.
• Supports IEEE 802.11a/b/g/n/ac WLAN standards.
Ships from Canada.
Qualcomm Atheros QCA9377
• Single-die wireless local area network (WLAN) and Bluetooth (BT) combination solution
• Supports 1x1 IEEE 802.11b/g/n at 2.4GHz
• Supports 1x1 IEEE 802.11a/n/ac at 5GHz
• Provides a highly integrated WLAN system-on-chip (SoC)for 5 GHz 802.11ac, or 2.4 GHz/5 GHz 802.11n WLAN applications
• Supports Bluetooth 5.0 + HS, BLE, and ANT+ with backward compatibility for BT 1.x, BT 2.x, BT4.2 + Enhanced Data Rate
• Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz
• Supports multiuser MIMO
• Supports BT-WLAN coexistence and ISM-LTE coexistence
• Supports IEEE 802.11d, e, h, i, k, r, v, and w
• Supports Dynamic Frequency Selection (DFS)
Manufacturer Lead Time:: 60weeks
Ships from Canada.
WLM200N2-26dBm MiniPCI wireless network adapter provides the leading performance of 802.11g/n . It supports upto 300Mbps physical data rates and upto about 200Mbps actual user throughput for both the uplink and downlink.
WLE600NX is a full-size mini PCIe wireless network adapter providing the leading performance of 802.11/a/b/g/n/ac. It supports up to 300Mbps physical data rates and about 200Mbps of actual user throughput for both the up link and down link.
Qualcomm Atheros QCA9890
• 2.4GHz, 3x3 MIMO OFDM Technology, up to 600Mbps physical data rate
• 5GHz, 3x3 MIMO OFDM Technology, up to 1300Mbps physical data rate
Manufacturer Lead Time:: 60weeks
Ships from Canada.
WLE200NX is a full-size mini PCIe wireless network adapter providing the leading performance of 802.11/a/b/g/n. It supports up to 300Mbps physical data rates and about 200Mbps of actual user throughput for both the uplink and downlink.
Limited Stock
Ships from Canada.
WLE200NX is a full-size mini PCIe wireless network adapter providing the leading performance of 802.11 a/b/g/n. It supports up to 300Mbps physical data rates and about 200Mbps of actual user throughput for both the uplink and downlink.
Qualcomm Atheros QCA9994
• 2.4GHz, 4x4 MU-MIMO OFDM Technology, up to 800Mbps physical data rate
• 5GHz, 4x4 MU-MIMO OFDM Technology, up to 1733Mbps physical data rate
• Dual Band 2.4/5GHz 4x4 WiFi 5 (802.11ac Wave 2)
• MiniPCIe interface with PCIe 2.0
• Heat sink allows free air operation
• Supports IEEE 802.11d, e, h, i, j, k, r, u, v time stamp, w, and z standards
• Supports Dynamic Frequency Selection (DFS)
Ships from Canada.
Dual Band Dual Concurrent 2.4GHz, 5GHz WiFi + Bluetooth 5.1 Combo m.2 Double
Ships from Canada.
Qualcomm Atheros QCA9994
• 5GHz, 4x4 MU-MIMO OFDM Technology, up to 1733Mbps physical data rate
• Single Band 5GHz 4x4 WiFi 5 (802.11ac Wave 2)
• MiniPCIe interface with PCIe 2.0
• Full size form factor with 80+80MHz bandwidth support
• Heat sink allows free air operation
• IEEE 802.11ac compliant & backward compatible with 802.11a/n
• 4 spatial streams (4SS) at 80MHz
Ships from Canada.
Qualcomm Atheros QCN9024/9074
• 2.4GHz, 4x4 MU-MIMO OFDMA Technology, up to 1376.4Mbps physical data rate
• Single Band 2.4GHz 4x4 WiFi 6 (802.11ax)
• M.2 E Key interface with PCIe 3.0
• 4 spatial streams (4SS)
Manufacturer Lead Time:: 60weeks
Ships from Canada.
Dual Band 3×3 802.11ac Module
Qualcomm-Atheros QCA9880
Ships from Canada.
Compex WLM54G-26dBm mini PCI wireless network adapter offers high output power of 400mW, extending the range of embedded devices much further. Combined with excellent receiver sensitivity.
Compex introduces the WLM54G-30dBm-ESD wireless 802.11b/g miniPCI high power of 30dBm (1 Watt) with ESD protection.
