4-channel I2C-safe Bi-directional Logic Level Converter
Raspberry Pi 3 Model B 1GB
Reference: RBMODB3
US$39.95
- 1.2GHz QUAD Core Broadcom BCM2837 64bit ARMv8 processor
- BCM43438 WiFi on board
- Bluetooth Low Energy (BLE) on board
- 1GB RAM
- 4x USB 2 ports
- 40pin extended GPIO
- HDMI and RCA video output
The Raspberry Pi 3 is the third generation Raspberry Pi. Compared to the Raspberry Pi 2 it has:
- A 1.2GHz 64-bit quad-core ARMv8 CPU
Like the Pi 2, it also has:
- 4 USB ports
- 40 GPIO pins
- Full HDMI port
- Ethernet port
- Combined 3.5mm audio jack and composite video
- Camera interface (CSI)
- Display interface (DSI)
- Micro SD card slot (now push-pull rather than push-push)
- VideoCore IV 3D graphics core
The Raspberry Pi 3 has an identical form factor to the previous Pi 2 (and Pi 1 Model B+) and has complete compatibility with Raspberry Pi 1 and 2.
We recommend the Raspberry Pi 3 Model B for use in schools, or for any general use. Those wishing to embed their Pi in a project may prefer the Pi Zero or Model A+, which are more useful for embedded projects, and projects which require very low power.
RBMODB3
Data sheet
- Processor (CPU)
- 1.2GHz QUAD Core Broadcom BCM2837 64bit ARMv8 processor
- Graphic Chipset
- Broadcom VideoCore IV
- Board Size
- 85.60 mm × 56.5 mm
- RAM
- 1 GB (Shared with GPU)
- Storage
- MicroSDHC slot
- Ethernet Ports
- 1 x 10/100 Mbit/s
- OS Support
- Linux (e.g. Raspbian), RISC OS, FreeBSD, NetBSD, Plan 9, Inferno, AROS, additional distributions of Linux such as Ubuntu
- Power
- 4.0W (5 V via MicroUSB or GPIO header)
- Weight
- 45 grams
- Return Warranty
- No Returns
- Manufacturer Warranty
- No Returns
- 1.2GHz QUAD Core Broadcom BCM2837 64bit ARMv8 processor
- BCM43438 WiFi on board
- Bluetooth Low Energy (BLE) on board
- 1GB RAM
- 4x USB 2 ports
- 40pin extended GPIO
- HDMI and RCA video output
