C1 3.2inch TFT+Touchscreen Shield
C1 3.2inch TFT+Touchscreen Shield

C1 3.2inch TFT+Touchscreen Shield

US$39.95
Tax excluded

Fully assembled 3.2inch display with 320x240 pixels TFT LCD and a resistive touch overlay. Just plug it on top of ODROID-C1. 2x13 tall female header is already soldered on the PCB.

In Stock



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

Ships directly from Canada same day

Fully assembled 3.2inch display with 320x240 pixels TFT LCD and a resistive touch overlay. Just plug it on top of ODROID-C1. 2x13 tall female header is already soldered on the PCB.
Fast 30Mhz SPI is used for the faster frame rate.

You will need an official Ubuntu image to configure it.
You can simply download the Kernel updates and configure your ODROID-C1 for this display shield.
Please follow the step by step guide from the WiKi. If not, the display doesn't work.

http://odroid.com/dokuwiki/doku.php?id=en:c1_lcdshield


Note: this display is NOT compatible with Android platform.
* Limitation : GPU/VPU Hardware acceleration required OpenGL-ES and Video playback are not supported.
To playback a video on this screen, you need a trans-coded 320x240 video file with FFMPEG software decoding.



PACKAGE INCLUDES :
You will see a fully assembled C1 3.2inch Touchscreen Display Shield and a Stylus pen.

Detail parts of the shield
- 3.2inch display with 320x240 pixels
- Resistive touch overlay
- Converter board with 3 buttons
- 2x13 female header
.

ODTFTTSS

Data sheet

Resolution
320 x 240 pixels
LCD
TFT, SPI Interface
Aspect Ratio
4:3
Touch Screen
Resistive
Touch Screen Controller
XPT2046 (SPI)
Colors
65536 (16bit RGB-565)
Weight
44 g
Board Category
ODROID-N2+, ODROID-C0, ODROID-C4, ODROID-C1+
Return Warranty
No Returns
Manufacturer Warranty
No Returns
