In Stock, Shipping Now
US$99.95

The ODROID-GO Super is a portable gaming console powered by the ESP32-WROVER microcontroller. It features a 3.5-inch IPS LCD display, Wi-Fi, Bluetooth, and a rechargeable battery. The console comes with pre-installed emulators and games, and its open-source nature allows for easy customization and game development.

Case Color:
  • Clear (Transparent)
  • Solid Gray

Description

Hardkernel has upgraded the OGA hardware design, and call it OGS (ODROID-Go Super).

The LCD size changed from 3.5 inches to 5 inches with a tempered cover glass. The resolution has changed from 480x320 to 854x480 pixels. The battery capacity has also increased by around 30%. The OGA had a 3000mAh battery while this new OGS has a 4000mAh battery.

You can consistintly play games for several hours depending on backlight brightness settings.

Additionally, other important hardware changes were made. Hardkernel added a second analog joystick and dedicated volume buttons.

The OGS is now pre-assembled in their factory instead of being a DIY assembled kit.

Since there is no built-in slow wireless connectivity, support for a faster USB WIFI+BT was improved.

Finally, the micro-SD card slot has been updated to push-push type (spring eject) from push-pull one.

Note* Other than that, basic hardware specification and emulation performance are very similar to the original OGA.

Note* An 8GB or higher capacity microSD card is required to install the operating system and games.

.
Header(P2) Description

PIN # GPIO TYPE FUNCTION SYSFS #
1 GND POWER
2 GPIO3_C1 IN/OUT I2S_MCLK #
3 GPIO3_C2 IN/OUT I2S_LRCKTX #
4 GPIO3_C3 IN/OUT I2S_SCLKTX #
5 GPIO3_C4 IN/OUT I2S_SDO0 #
6 3.0V POWER
7 GPIO3_C5 IN/OUT I2S_SDI1 #
8 GPIO3_C6 IN/OUT #
9 GPIO3_C7 IN/OUT #
10 5.0V POWER





Product Details

CPU
RockChip RK3326(Quad-Core ARM 64bit Cortex-A35 1.3GHz)
Memory
1GB (DDR3L 786Mhz, 32 Bits bus width)
Storage Capacity
SPI Flash(16Mbytes Boot), Micro SD Card slot(UHS-1 Capable interface)
Audio Output
Earphone stereo jack, 0.5Watt 8Ω Mono speaker
Display Output
5inch 854×480 TFT LCD (Wide viewing angle display, MIPI-DSI interface)
External I/O
USB 2.0 Host x 1, 10Pin port(I2C, GPIO, IRQ at 3.3Volt)
OS Support
Ubuntu 18.04. 19.10 and 20.04 on Kernel 4.4 Aarch64
Width
204mm
Height
25mm
Length
204mm
Wireless
Optional USB WiFi adapter
Color
Dim Gray and Transparent
Board Category
ODROID Accessories
Weight
280g
