Step up DC-DC
Step up DC-DC

Step up DC-DC

US$2.25
Tax excluded

Note: Input voltage should be no more than rated voltage,or the module will be burnt

Directly Ship from Canada



Secure Transaction



Shipping Directly from Canada



Customer-Friendly Return Policy

- Input Voltage:0.9-5V
- Output voltage:5V
- Maximum Output Current: 480mA
- Starting Up Voltage:0.8V;output current:7mA
- Input Voltage:1-1.5V;output voltage 5V;current 40-100mA
- Input Voltage:1.5-2V;output voltage 5V;current 100-150mA
- Input Voltage:2-3V;output voltage 5V;current 150-380mA
- Input Voltage:>3V;output voltage 5V;current 380-480mA
- Operating Frequency:150KHz
- Typical Conversion Efficiency:85%
- Pin Space:2.54mm
- Size:11*10.5*7.5mm

Notice:
1.Input voltage should be no more than rated voltage,or the module will be burnt
2.Input power should surpass output power,or output voltage will be less than rated voltage
3.Output load should be no more than rated load,or output voltage will be less than rated voltage

example : https://wiki.odroid.com/odroid_go/arduino/31_ultrasonic_distance_meter
