Silver Indoor Enclosure ALIX2D2 - 2 LAN
Reference: CASE1D1U
US$14.95
Enclosure designed for ALIX.2* boards. Cutouts for 3 LEDs and 1 switch in front, cutouts for DB9, 2 LAN, 3 or 2 SMA connectors, DC jack in back. Enclosure made of anodized or painted aluminum. Dimensions 168 mm wide x 157 mm deep x 30 mm high. RoHS compliant.
Enclosure designed for ALIX.2* boards. Cutouts for 3 LEDs and 1 switch in front, cutouts for DB9, 2 LAN, 3 or 2 SMA connectors, DC jack in back. Enclosure made of anodized or painted aluminum. Dimensions 168 mm wide x 157 mm deep x 30 mm high. RoHS compliant.
Assembly notes
Tools needed: Phillips screw driver, 5 mm or 3/16" nut driver. Remove hex nuts from DB9 connector of ALIX board. Mount ALIX board in enclosure, then fasten all screws and hex nuts. CF card can be secured with Kapton tape to the CF socket, or a strip of elastic rubber (e.g. sealing strip for windows) on the inside of the top cover.
CASE1D1U
Data sheet
- Compatible with
- ALIX2D2
- Color
- Silver
- Screws
- 8
- Back Cutouts
- 1 x DC Power Jack, 1 x DB9 Serial, 2 x Ethernet, 2 x USB and 3x SMA antenna Connector
- Front Cutouts
- 3 LEDs and 1 Reset
- Material
- Anodized or painted aluminum
- Application
- Indoor
- Package Includes
- 1 x Enclosure top, 1 x Enclosure base, 4 x screws to mount system board, 4 x Screws to close enclosure, 4 x Self-Adhesive Feet, 3 x Rubber Plugs for unused SMA holes
- Depth
- 157mm
- Weight
- 330g
- Width
- 168mm
- Height
- 30mm
- Certificate
- RoHS
- Board Category
- ALIX
- Return Warranty
- Standard 30 Days
- Manufacturer Warranty
- No Returns
Enclosure designed for ALIX.2* boards. Cutouts for 3 LEDs and 1 switch in front, cutouts for DB9, 2 LAN, 3 or 2 SMA connectors, DC jack in back. Enclosure made of anodized or painted aluminum. Dimensions 168 mm wide x 157 mm deep x 30 mm high. RoHS compliant.
