Works with the ODROID-C2 / C1+. This is not compatible with the original ODROID-C1.

The HiFi Shield Plus provides both stereo RCA connectors and a 3.5mm stereo jack (all gold-plated) to connect to external amplifiers and other audio equipment. Via TI's high-end PCM5102 DAC chip(known as Burr-Brown), it supports 16, 24, 32 bit audio formats with minimal distortion (-93dB) and ideal dynamics (110dB+), plus amazing sampling rates of 384kHz

The dedicated S/PDIF interface is newly added which supports up to 192kHz/24bit resolution via new Optical (Toslink) output.

Using the I2S expansion on the C2 / C1+, we save a USB port and allow the user to select their audio playback system of choice, such as Volumio, RuneAudio or XBMC/Kodi for HiFi audio playback.

Functional introduction:

  1. The output ports include gold-plated stereo RCA terminals and a 3.5mm audio jack.

  2. An ultra-low noise dropout regulator is coupled with two solid capacitors for the power supply, significantly reducing power supply noise and greatly increasing the signal to noise ratio.
  3. The I2S interface allows for direct decoding of the digital input to analog output using master clock synchronization.
  4. The PCB surface is comprised of gold-plating on top of 2 oz. of copper, ensuring signal continuity and reducing signal reflection and refraction.


- Ubuntu/Linux setup guide for ODROID-C2 : HERE / for ODROOID-C1+ : HERE
- Official Volumio OS support : https://volumio.org
- Official Runeaudio OS support : https://runeaudio.com

- PCB mechanical drawings (AutoCAD format) : Download HERE
- Schematics : Download HERE

* This HiFi shield is not functional with Android. We have no plan to support the Android OS to enable the I2S driver for Android Kernel and HAL



ODHIFIP

Data sheet

Board Category
ODROID-C1+
ODROID-C2
ODROID-C4
